| TECHNICAL SPECIFICATIONS | |
|---|---|
| Theoratical Capacity | 175-185 m3/h |
| Aggregate Bunker Type | In-Line |
| Aggregate Bunker Capacity | 2*(2*40 m3) |
| Aggregate Loading Type | Transfer Conveyor |
| Mixer Type | Twin Shaft |
| Mixer Volume | 7500 lt. |
| Mixer Output Capacity | 5000 lt. |
| Mixer Motor Power | 2*90 kw |
| Cement Weighing System | 2700 kg |
| Water Weighing System | 1300 kg |
| Additive Weighing System | 2*50 lt. |
| Automation/Software | Helvetia |
| Electrical Equipment(Hardware) | Schneider/Siemens |
| Installed Electrical Power | 300-305 kw |
| Absorbed Electrical Power | 225-230 kw |
Helvetia S180 is a versatile concrete batching plant model that is equipped with a double shaft or planetary mixer with a capacity of 7500/5000 liters. It has the capacity to produce 175-185 m3 of concrete per hour.
This model can also be preferred without a mixer for dry type concrete batching plant production. The prominent features of this model are as follows:
- Easy Installation: Its modular structure enables easy and hassle-free installation.
- High Production Performance: It delivers high production performance, ensuring efficient concrete production.
- Easy Maintenance and Low Operating Costs: The model is designed for easy maintenance and is cost-effective to operate.
